TH40 Thermostat with contact sensor for frost protection

Cables chauffant autorégulant
Thermostat TH40 avec sonde de contact pour la protection hors-gel
search
  • Thermostat TH40 avec sonde de contact pour la protection hors-gel
  • Schéma d'installation Thermostat TH40 avec sonde de contact pour la protection hors-gel

Photos non contractuelles

Frost protection thermostat

Function:

The TH40 thermostat maintains a precise set temperature and cuts off power above that level to save energy.

This thermostat saves electricity by activating the system (and thus the cable) only when the temperature falls below a preset value for frost protection.

Sensor length: 3 m (This length can be extended up to 10 m using 2 x 1 mm² cable)

Plus de détails
1
Are you an individual?
Are you a professional?

Log in to find out your discount.

€140.33 Tax included

116.94 € tax excl.

Unité de vente : Pièce
TH4000000000000
Quantity

Consulter les produits disponibles sous forme de liste
Are you an individual?

Save time and have it delivered to your workplace..

Are you a professional?

Turn your personal account into a pro account and get discounts and preferential rates.. More about the pro account

Complément d'information TH40 Thermostat with contact sensor for frost protection

The tables and information provided on this page are for indicative purposes only. For tolerances and exact specifications, please refer to the applicable product standards.

Frost protection

  • To optimize the system’s energy consumption, it is recommended to install a TH40 thermostat (0°C to 40°C), which will only activate the system when the temperature falls below the set point.
  • Proper positioning of the thermostat’s temperature sensor is essential. It must be placed under the insulation, against the pipe, at the point known to be the coldest in the system.

Reminder:

Depending on the total length of cable installed, a power relay should be provided, taking into account the breaking capacity of the thermostats in the range (TH40: 16 A, TH110: 10 A).

Electrical Connections

  • First, the system must be protected at the supply end by a 30 mA ground-fault circuit interrupter (GFCI) combined with a Type C circuit breaker for the pipe tracing. The amperage of this circuit breaker must be selected based on the length of the system’s cable.
  • The installation must be carried out in accordance with current electrical regulations.

Power supply cable for the heating cord:

The maximum length will depend on the circuit breaker’s maximum amperage:

Circuit Breaker Power cable Max. length
10 A 3 x 2.5 mm² 60 m
16 A 3 x 2.5 mm² 40 m
25 A 3 x 2.5 mm² 35 m

Electrical connection of the AUTOCÂBLE cord (with power relay):

Beyond the maximum lengths and amperage supported by the thermostat, given its maximum breaking capacity, it is necessary to use a power relay. This allows a single thermostat to be used for longer cable lengths.

Caractéristiques techniques TH40 Thermostat with contact sensor for frost protection

Data sheet

Reference
TH4000000000000
Unité de vente
Pièce
Garantie fabricant
1 an

Specific References

ean13
5703502520940

Download documentation

Câble chauffant autorégulant

Brochure commerciale Câble chauffant autorégulant AUTOCABLE

Download (4.3MB)

FT TH40

Fiche technique Thermostat TH40 avec sonde de contact

Download (684.13KB)
