1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class -1 / +1b (bar)

Manomètres
Manomètre axial à bain de glycérine, boîtier inox 10 bar
search
  • Manomètre axial à bain de glycérine, boîtier inox 10 bar
  • DIMENSIONS ( en mm ) 1612-1625
  • GRADUATIONS - NOMENCLATURE 1612-1625

Photos non contractuelles

Stainless steel pressure gauge, Ø50, polycarbonate face, glycerin-filled, 2.5% accuracy class, with a male BSP DN8 ~ 1/4'' axial brass connection

Application:

  • For all gaseous and non-viscous or crystallizing liquids that do not attack copper alloys
  • Hydraulics, compressors, and shipbuilding
  • Minimum and maximum permissible temperature Ts: 0°C to +60°C

Available in:

Diameter Ø 50 with 1/4" axial fitting, pressure range from -1/+1 to 0/60 bar

Plus de détails
Type de raccordement : Á visser BSP (pas du gaz)1
-1 / +1b (bar)
Are you an individual?
Are you a professional?

Log in to find out your discount.

€12.91 Tax included

10.76 € tax excl.

Unité de vente : Pièce
MIBLG3ALMB08101
Pressure range: -1 / +1B (Bar)
Quantity

Consulter les produits disponibles sous forme de liste
Are you an individual?

Save time and have it delivered to your workplace..

Are you a professional?

Turn your personal account into a pro account and get discounts and preferential rates.. More about the pro account

Complément d'information 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class

The tables and information provided on this page are for indicative purposes only. For tolerances and exact specifications, please refer to the applicable product standards.

Features:

  • 304 stainless steel housing
  • Tin-soldered brass Bourdon tube
  • Brass fitting
  • Polycarbonate window
  • With glycerin
  • Class 1 for 100 mm diameter
  • Class 1.6 for 63 mm diameter
  • Class 2.5 for 50 mm diameter
  • IP65 protection
  • BSP fittings
  • Dual bar/psi scale for 63 mm diameter
  • With safety vent for 100 mm diameter (Ref. 1615 and 1625)

Caractéristiques techniques 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class

Data sheet

Reference
MIBLG3ALMB08101
Remplissage
Bain glycérine
Graduation
0-10B
Type de raccordement
Á visser BSP (pas du gaz)
Raccordement
Axial
Diamètre
1/4"
Unité de vente
Pièce
Garantie fabricant
1 an

Specific References

ean13
3598780015248

Download documentation

FT 1622

Fiche technique manomètre boitier inox D50 raccord arrière axial 1/4''

Download (453.53KB)

Accessoires et équipements (vendus séparément)

Caractéristiques liées à la version du produit 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class

Voici la liste des références et poids correspondants aux options séléctionnées.
MIBLG3ALMB08101 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - -1 / +1B (Bar)
Pressure range -1 / +1B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08001 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +1,6B (Bar)
Pressure range 0 / +1,6B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08002 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +2.5B (Bar)
Pressure range 0 / +2.5B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08004 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +4B (Bar)
Pressure range 0 / +4B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08006 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +6B (Bar)
Pressure range 0 / +6B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08010 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +10B (Bar)
Pressure range 0 / +10B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08016 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +16B (Bar)
Pressure range 0 / +16B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08025 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +25B (Bar)
Pressure range 0 / +25B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08040 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +40B (Bar)
Pressure range 0 / +40B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
MIBLG3ALMB08060 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +60B (Bar)
Pressure range 0 / +60B (Bar)
Packed weight 0,168kg
10.76 € tax excl.
Consulter
Référence - Désignation Pressure range Packed weight Prix
MIBLG3ALMB08101 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - -1 / +1B (Bar) -1 / +1B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08001 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +1,6B (Bar) 0 / +1,6B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08002 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +2.5B (Bar) 0 / +2.5B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08004 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +4B (Bar) 0 / +4B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08006 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +6B (Bar) 0 / +6B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08010 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +10B (Bar) 0 / +10B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08016 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +16B (Bar) 0 / +16B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08025 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +25B (Bar) 0 / +25B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08040 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +40B (Bar) 0 / +40B (Bar) 0,168kg 10.76 € tax excl.
MIBLG3ALMB08060 - 1/4'' axial glycerin-filled pressure gauge, stainless steel case, Ø50, 2.5% accuracy class - 0 / +60B (Bar) 0 / +60B (Bar) 0,168kg 10.76 € tax excl.
